Leica APO-Vario-Elmarit-SL 90-280mm F/2.8-4

Angle of view (diagonal, horizontal, vertical) : For Leica SL (Typ 601): approx. 26°, 22°, 15° / 9°, 7,5°, 5°, for Leica T (type 701): approx. 17°, 15°,10°* / 6°, 5°, 3°** (corresponding to approx. 135*/420** focal length in 35 mm format)


Optical design : Number of lenses/groups : 23/17

Aspherical surfaces : 4

Position of entrance pupil : 90/280 mm: 130,2/-21,1 mm (in thedirection of light incidence in front of/behind bayonet fitting contact area)

Image stabilization: Multiple axis system, stabilization performance 3.5shutter speed stages in accordance with CIPA testing conditions

Distance setting : Either automatic (Autofocus) 4 or manual, modes are set on the camera

Focusing range: (at 90 / 280mm):Smallest object field/Biggest scale (at 90 / 280mm): 0.6/1.4 m For Leica SL (Typ 601): approx. 114 x 171 mm/1:4.8 / 120 x 180 mm/1:5,
for Leica T (Typ 701): approx. 76 x 114 mm/1:4.8 / 80 x 120 mm/1:5

Aperture : Electronically controlled aperture, setting via turn/push wheel on camera, half values can also be set

Lowest value : 22

Bayonet fitting: Leica L bayonet fitting with contact strip

Filter mount/lens hood : External bayonet fitting for lens hood (included), internal thread for E82 filters, filter mount does not rotate

Finish : Black anodized

Dimensions and weight: Length of the bayonet fitting contact surface : Approx. 238/310 mm (without/with lens hood)

Largest diameter approx : 88 mm

Weight approx : 1850 grams
